1. Frequency range: 25Hz – 200Hz

2. Rated power: 1000W (continuous)

3. Impedance: 4 Ω

4. Maximum sound pressure level: 136dB

5. Composition: 12 "x2 long occurrence driver

6. Sensitivity: 108db

7. Speaker size: mm (width 380, depth 650, height 850)

8. Rated output power: 1200W + 2 × 400W/8Ω， 2000W+2 × 700W / 4 Ω

9.2 channels of 6.3 composite XLR analog signal input, 2 channels of link signal output and 2 channels of RCA input

10. Input sensitivity: balanced signal 0.77v, unbalanced signal 1.4V,

11.2 in and 4 out 48K / 24bit high-performance DSP audio Processor

12. The panel has LCD display and archive mode call knob, which can call 30 preset archive modes

13. USB computer online function, convenient and fast

14. Frequency response Range: 20Hz-20KHz, signal-to-noise ratio: > 106 DB

15. Protection function: short circuit, overload, over temperature, amplitude limiting, startup delay

16. High strength thickened aluminum alloy heat dissipation panel

17. Dimension of active module (H x W x D mm): 360x280x85
