1. Service voltage: AC 220V 50Hz

2. Power output: 8 channels controllable, one channel direct output

3. Action delay: 0 to 240 seconds, never open

4. Maximum current: 30 a @ 220V 50Hz

5. Display contents: current time, status of each circuit, voltage status, weekly plan, cascade status

6. Display mode: 12864 dot matrix display

7. Single circuit current: 13A

8. Protection range: under voltage 170 to 190 V, over voltage 240 to 260 V adjustable

9. Timing mode: within a week, 8 time periods of any day can be set

10. Communication protocol: UDP

11. Interface mode: RJ45 (including one of 485 and built-in network switch)

12. Scenario: 8 adjustable, panel and weekly tasks can be called arbitrarily

characteristic

1. Built in 12864 intelligent display window, which can display various parameters in real time.

2.8 switch channel outputs, and the start delay and stop delay time of each channel can be set freely for 0-240 seconds,

Or no action.

3. Ensure personal safety with low-voltage meter.

4. It has password lock function to prevent misoperation.

5. Built in clock chip to display the current date and time in real time

6. One week plan management. From Sunday to Saturday, the machine is switched on and off for 8 time periods every day without personnel operation

7. Plan management today. You can temporarily cancel or increase the start-up time period of this day

8.8 saving and calling of switching scenarios of group equipment can be applied to different occasions

9. Undervoltage and overvoltage detection protection and alarm

10. The panel is directly controlled, which can directly control the operation of any channel switch, which is convenient and simple

11. Network management function, which can manage any sequencer in the same LAN

12. Mobile app and computer operation interface are intuitive and convenient.
