1. Frequency range: 30Hz – 200Hz

2. Rated power: 800W (continuous)

3. Impedance: 4 Ω

4. Maximum sound pressure level: 133dB

5. Composition: 10 "x2 long occurrence driver

6. Sensitivity: 105dB

7. Dimension: mm (width 325, depth 570, height 695)

8. Rated output power: 1000W + 400W / 8 Ω, 2000W + 700W / 4 Ω,

9.2 channels of 6.3 composite XLR analog signal input, 2 channels of link signal output and 2 channels of RCA input

10. Input sensitivity: balanced signal 0.77v, unbalanced signal 1.4V

11.2 in and out 48K / 24bit high-performance DSP audio processor

12. The panel has LCD display and archive mode call knob, which can call 30 preset archive modes 13. USB computer online function, convenient and fast

14. Frequency response range: 20Hz-20KHz, signal-to-noise ratio: > 106 DB

15. Protection function: short circuit, overload, over temperature, amplitude limiting, startup delay

16. High strength thickened aluminum alloy heat dissipation panel
