Frequency range: 40Hz – 200Hz
Rated power: 400W (continuous)
Impedance: 8 Ω
Maximum sound pressure level: 118db
Composition: 12 "L × 1 (190 magnetic 100 core)
Sensitivity: 93dB
box wood: birch plywood
Paint: Black waterborne paint
Size: mm (width 370, depth 400, height 450)
Active module:
● rated output power: 600W × 1/8Ω， 700W × 1 / 4 Ω
● one XLR analog signal input, one link signal output and two RCA signal inputs
● input sensitivity: 0.77v for balanced signal and 1.4V for unbalanced signal
● the panel is equipped with high cut knob and phase adjustment button
● frequency response range: 20HZ-200HZ, signal-to-noise ratio: > 106 dB
● protection function: short circuit, overload, over temperature, amplitude limiting, startup delay
● high strength thickened aluminum alloy heat dissipation panel
