1. Unit composition: Bass 1 × 12 "(170 magnetic 75mm), treble 1 × 1.73"(44mm)

2. Frequency division point: 1.8khz built-in frequency division network

3. Connection - input: 1 × NL4, output: 1 × NL4

4. Connection mode: ± 1... LHF

5. Box type: trapezoidal box

6. Material: imported high-quality multilayer splint

7. Surface treatment - box body: black polyurethane spraying; Surface mesh: Black porous powder spraying steel mesh and sound transparent speaker mesh

8. Rated power: 300W

   Continuous power: 600W

   Maximum power: 1200W

9. Directivity: 80 ° × 50°（H × V）

10. Sensitivity (1W / 1m): 95dB SPL

11. Maximum sound pressure level: 126dB SPL

12. Rated impedance: 8 Ω

13. Frequency response: 50Hz-18KHz

14. Product size (w * D * h): 594 * 484 * 322mm

15. Net weight: 19.6 kg
