1.12 channel design, 8-Channel mic mono + 2-channel stereo input

2. Single channel 100Hz low frequency attenuation switch (high pass filtering)

3. Three sections of parameter equalization per channel, mono band sweep

4.4 Auxiliary Marshalling output, 2 turn back before pusher, 1 auxiliary after attenuation, 1 Effect after attenuation, 3 groups of aux bus auxiliary output (including eff)

5. Built in 24 kinds of DSP digital effectors, built-in USB player, MP3 player, USB in-line recording

6. The built-in Bluetooth 5.0 receives and plays, and the USB audio card (connected to the computer) transmits the sound played by the computer to the mixer

7. Built in 48V fantasy power supply, with independent switch for each channel

8. Main output dual 7-segment stereo graphic equalizer, USB can be switched with one channel stereo, USB can be adjusted independently, mp3 can be switched with one channel stereo, mp3 can be adjusted independently

9. Each input channel is equipped with on switch, pel earphone switch, 12 segments of accurate three color LED level light to display the signal status, smooth and high-quality 100mm travel pusher

10. Dimension L × W × H (length, width and height):440*460*145 (mm)

11. Net weight: 7.5kg

Technical parameters:

1. Input sensitivity: Microphone: -60db

2. Stereo channel input: -40db

3. Effect transmission: -20db

4. Effect return: -20db

5. Output: max. 4V

6. Signal to noise ratio s/n:83db

7. Equalization: ± 15dB

8. High frequency: ± 15db/10khz

9. If: ± 15db/250khz~6khz

10. Low frequency: ± 15db/60hz

11. Maximum output level: 20dbm

12. Total harmonic distortion: 0.02% @ 0db1khz

13. Corresponding frequency: 20hz~20kz

14. Power output power: 30W

15. Power supply voltage: 100v-240v/50hz
