Functional features

music

1. Music parameter Equalization: 7 segments

2. Music to main output high pass filter: 12dB / 24dB (0Hz - 303hz)

Microphone

1. There are four microphone FBE modes: off 1 2 3

2. Microphone voltage limit function

3. 15 segment microphone parameter equalization

effect

Echoes:

1. Echo low-pass filter: 5.99hz - 20.6khz

2. Echo high pass filter: 0Hz - 1000Hz

3. Echo parameter Equalization: 3 segments

4. Echo level: 0 ~ 100%

5. Direct echo sound level: 0 ~ 100%

6. Echo pre delay: 0 ~ 500ms

7. Pre delay of echo right channel: 0 ~ ± 50% (relative to left channel)

8. Total pre delay of echo: 0 ~ 500ms

9. Echo right channel delay: 0 ~ 50% (relative to echo delay time of left channel)

10. Echo repetition: 0 ~ 90%

reverberation

1. Adjustable range of reverberation low-pass filter: 5.99hz - 20.6khz

2. Adjustable range of reverberation high pass filter: 0Hz - 1000Hz

3. Adjustable range of reverberation level: 0 ~ 100%

4. Adjustable range of reverberation direct sound: 0 ~ 100%

5. Adjustable range of echo pre delay: 0 ~ 200ms

6. Adjustable reverberation time range: 0 ~ 3000ms

Main output (working mode: singing / hot dancing (automatic / manual), including all parameters except pressure limit, delay and mute)

1. Music level: 0 ~ 200%

2. Direct sound level: 0 ~ 200%

3. Echo level: 0 ~ 200%

4. Reverberation level: 0 ~ 200%

5. Parameter equalization of 5 pieces of music

6. Compression limiter

7. Left channel delay: 0 ~ 50ms

8. Right channel delay: 0 ~ 50ms

9. Left channel mute function

10. Right channel mute function

Central output (working mode: singing / hot dancing (automatic / manual), including all parameters except pressure limit, delay and mute)

1. Music level: 0 ~ 200%

2. Direct sound level: 0 ~ 200%

3. Echo level: 0 ~ 200%

4. Reverberation level: 0 ~ 200%

5. High pass filter: 0Hz - 303hz

6. 3-stage parametric equalization

7. Compression limiter

8. Delay: 0 ~ 50ms
