1. Display size: 7 inches

2. Resolution: 1024x600

3. Touch resistance

4. Master CPU: Samsung 4418 4-core cortex ™- A9

5. Startup speed: 22 seconds

6. Operating system: Linux

7.DSP：ADSP-21489 400Mhz

8. Analog input: 16CH (14mic + 2line)

9. Digital input: S / P DIF, optical fiber

10. Digital output: AES EBU

11. USB: recording / playing, playing format ape, FLAC, MP3, wav

12. Analog output: L / R + 6bus + 2aux + headphone (L / R)

13. Output bottom noise: - 90dbu without recording weight (AP 515 test aes17-20khz)

14. Speech amplifier bottom noise: 30dbu speech amplifier gain -86.8dbu without recording weight (AP test aes17-20khz)

15.40dbu: speech amplifier gain - 80dbu without recording weight (AP test aes17-20khz)

16. Distortion: 0.005% @4dbu 20 ~ 20KHz

17. Sex noise ratio: - 108db, no recording weight

18. Dynamic range: 108db

19. Frequency response: 20Hz-20KHz ± 0.3dB

20. Maximum input / output level: 18dbu (6.2vrms) balanced

21. DCA: Yes

22. Chinese English interface: Yes

23. Electric pusher: 13

24. IPad control: Yes

25. Effector: 2 Effects

26. Feedback suppressor: 16 independent

27. Speaker Manager: Yes

28. Ethernet: 100M

29. RS-232 protocol: Yes

30. WiFi: 150m (optional)

31. Dante: Dante 4x4 (optional)

32. USB mouse: support

33. Dimension (w * D * h): 535x485x205mm

34. Power supply: AC 100v-240v; 50/60Hz  55W

35. Net weight: 10.7kg

36. Gross weight: 14.9kg

37. Package size: 635 * 580 * 335

1.7-inch resistive touch screen 1024x600 resolution

2.13 100mm electric pushers

3. The Chinese and English interfaces can be switched at any time without restart

4. Built in USB recording and playback function

5. It can play ape, FLAC, MP3 and wav lossless audio formats

6. The USB player can recognize Chinese song names

7. Built in 16 channel independent feedback Suppressors

8. Built in 16 channel automatic mixing

9. Integrated speaker Manager

10. Open the third-party control protocol TCP / IP and RS-232 control instructions

11. With 2 DCAS

12. IPad touch screen full function control, real-time data synchronization

13. Optional WiFi hotspot

14. Support simultaneous control of 8 terminals

15. Built in 2 effector modules

16. Arm firmware and DSP firmware can be upgraded through network or USB resistance disk

17. Each input channel has 4 sections of parameter equalization, noise gate, feedback suppressor, high-low pass, compression and inversion

18. Each output channel has 8-segment parameter equalization, high-low pass, compression, inversion and 1-second delay

19. Output channel L / R, 6bus, 2aux, headphone (L / R)

20.6 bus and 2 aux mixing bus can select before and after push (pre / post)

21. It supports 100 sets of scene preset functions, and can export and import USB memory for data backup

22.32 PEQ mode storage

23. Built in signal generator: sine wave, pink noise, white noise

24. Channel parameter copy function, the same channel can quickly copy data

25. Wiring mode: balanced input and output XLR

26.8 pusher groups, 1 system mute key and 3 fast mute keys

27. With panel locking key (to prevent misoperation)
