characteristic

1. Non PC architecture embedded system does not need to wait for startup program and control program execution process;

2. New industrial and 32-bit processor and quad core exynos8890 processor are adopted, with processing speed of more than 1.5GHz;

3. The built-in 600MHz DSP coprocessing chip is used to assist the main processor to process large capacity data; The operation of the system is more reliable and stable;

4. The latest programmable logic FPGA chip Stratix: Emoji: 10 is adopted, the internal core operation mechanism is built, there is no embedded operating system, and the performance is more stable;

5. The host has built-in 2G DDR2 Memory and 16g flash memory, which makes the system access speed fast and stable, and fully meet the current or future upgrade requirements;

6. Frequency conversion infrared learning function, covering infrared codes of all frequencies, excellent support for air conditioners and some extreme equipment that are difficult to learn;

7. Support seamless integration of cmmaw technology and CCSEB power management technology, enhance system operation stability, reduce energy consumption and support environmental protection

8. Support the storage and calling of central control status control mode, and can store up to 32 central control modes; Call mode supports speed control;

9. 8 independent programmable infrared transmitting interfaces, supporting 128 infrared devices at most;

10. 8-way RS232 supports international standard programmable interface and can send and receive 232 data;

11. 2-way RS485 supports international standard programmable interface and can send and receive 485 data;

12. 4-way custom digital I / O control port, trigger mode can be set arbitrarily;

13. 4-way weak current relay supports 5V / 9V / 12V / 24V / 1A control interface;

14. 1-way TCP / IP control bus, directly supporting Apple iPad, iPhone and Android platform handheld terminals (providing programming software); Support centralized management of large-scale networking

15. 1 kt-ai control bus; It can be directly connected to AI voice control system;

16. 1 channel DC24V output interface, connected to 8-channel power controller;

17. 1 independent computer control serial port;

18. Adopt the international popular SMT production process; International general power supply 110v-240v, suitable for any region;

19. At the same time, it supports wireless touch screen, wired touch screen, USB, serial port, computer, network, wall panel and other control modes;

20. The front panel has system hardware and software reset function keys and infrared direct recording function keys;

21. Open programmable control platform and humanized operation interface; Fully support third-party equipment and control protocols. Customers can set a variety of control protocols and codes by themselves, and fully support the products of most manufacturers in the industry on the market

Programming methods and engineering procedures to reduce the difficulty of on-site installation, commissioning and programming;

22. Built in monitoring module to detect various functional modules in the equipment. It can also monitor the working state and working temperature, and has the real-time alarm function of abnormal state;

23. Support multi code control, i.e. sending multiple codes (IR infrared, RS-485 code, RS-232 code) with one key;

24. The front panel has infrared code recording / transmission / reception / online / error led status lights;

25. Support network control and online program update;

26. It is applicable to large and medium-sized conference rooms, conference halls, academic lecture halls and other places.

It is suitable for solving various signal switching and functional control of various equipment in today's modern conference room; Through 1GHz high-speed processor, built-in 2G DDR2 Memory and 8g high-capacity flash memory, the system processing and access speed are fast and stable, and the requirements for proper upgrading in the later stage are also guaranteed. 8-way bidirectional programmable RS-232 ports and 8-way infrared output control ports. These practical and advanced configurations make the whole system more handy in the use of the project.
